Pail Printer-PM
Technical Data Sheet
|
Max printing speed |
200pcs/minor 400pcs/min(depend on specific products) |
|
Max pail height |
350mm |
|
Pail rim diameter |
70-320mm |
|
Pail taper |
0-12° |
|
Max printing height |
255mm |
|
Max printing length |
650mm (6 blankets) 890mm (3blankets) |
|
Colorhead |
8 |
|
Net.Weight |
15000KG |
|
Machine height |
3600mm |
|
Machine length |
8589mm |
|
Machine width |
4632mm |
PM
Register-accurate Plate Adjustment
Register-accurate plate adjustment achieves excellent printing results
Up to 8 colors to meet diversified printing requirements
Index Unit
Super customized index imported from Germany
Index brand: Heinz
50,000 hours free of maintenance
Liquid Cooling System
Constant temperature cooling system
ensures excellent printing performance
Gear(colour:gray-black)
Use imported special materials
Shock absorption and wear resistance
ensure sharp printing performance
Screw Ink Fountain
Control the amount of ink via screw tighten or loosen
Plate Cylinder
Run out ≤ 0.01mm
Measure after 24 hours constant temperature, the diameter difference of the 8 pcs plate cylinders is controlled less than 0.01mm
Mandrel
Run out ≤ 0.02mm
Keep the highest points of 8 pcs mandrel at the same level
Dia 1.8m Offset Cylinder
Run out ≤ 0.02mm
